Flextool Super Drive Unit + Sludge Pump + Lay Flat Hose Kit - FTDRAINAGEKIT2

Flextool Super Drive Unit + Sludge Pump + Lay Flat Hose All-In-One Kit! Ideal For Excavations Pits, Construction Sites, Pier Holes, Dams, Swimming Pools, Trenches

Powered by a Flextool 5.5HP Honda Petrol Powered Super Drive Unit (FT201798-UNIT), Flextool Pumps are highly efficient submersible units perfect for excavations pits, construction sites, swimming pools & much, much more! Flextool pumps are completely self-priming & extremely robust in their design. The flexible shaft drive facilitates use in many situations where close coupled pumps would not be suitable. The FP212 series come with Flexshaft support springs which protect the drive shaft when operating over the sharp edge of excavations, pits, dams, etc. These kits include the (FT201798-UNIT) Drive Unit, (FT201801-UNIT) Submersible Pump, & the (FT200032-UNIT) Layflat PVC Hose.

Applications

• Excavations pits
• Construction sites
• Pier holes
• Dams
• Swimming pools
• Trenches

Features

• Ideal Kit For Excavations Pits, Construction Sites, Pier Holes, Dams, Swimming Pools, Trenches & Much, Much More!
• Petrol Powered Drive Unit With Honda 5.5HP Engine (GX160)
• Submersible Pump Capable Of 28mm Solids Pumping Capacity
• 20 Metre Lay Flat PVC Hose With Fitted Coupling & Joiner

Includes

• 1 x (FT201798-UNIT) Flextool FDU-P2 5.5HP Honda Petrol Powered Super Drive Unit

The heavy-duty super Flextool Drive Unit FDU-P2 is designed for use in the construction, hire and manufacturing industries. It is fitted with a quick action coupling for easy connection to a wide range of flexible shaft submersible pumps and concrete vibrators. Features include a heavy-duty engine protection frame, rubber mounts for vibration isolation, and an oil-level sensor to protect the motor from a lack of crankcase oil. The FDU-P2 is powered by a Honda GX160 5.5hp petrol engine for hassle-free operation and low engine emissions. It has a lifting hook for easy and safe onsite handling, and a dished steel base for easy mobility over concrete reinforcing mesh.

Applications

• Compatible with Flextool Submersible Pumps & Flextool Flexshaft Concrete Vibrators
• Construction, hire industry & manufacturing industry

Features

• Honda GX160 petrol engine provides hassle-free operation and low engine emissions
• Universal bell housing fitted with 3-tooth drive coupling
• Compatible with most flexible shaft submersible pumps and concrete vibrators
• Heavy-duty powder-coated tubular steel roll frame for increased durability
• Central lifting hook for easy and safe onsite handling
• Heavy-duty rubber mounts for vibration isolation allowing sturdy operation when stationary
• Dished steel base plate for easy mobility over concrete reinforcing mesh
• This product is covered by the Flextool Promise

Specifications

Model	Super
Model Number	FDU-P2
Operating Weight	32kg
Engine Speed (Revolutions Per Minute)	3,000 RPM
Vibration Isolating Mounts	Yes
Lifting Hook	Yes
Engine Make	Honda
Engine Model	GX160
Max Rated Power (Hp)	5.5 HP
Fuel Type Petrol	Unleaded Petrol

• 1 x (FT201801-UNIT) Flextool FP212G 6m General Purpose Submersible Pump

Flextool Pumps are highly efficient submersible units which are operated by petrol or diesel portable drive units. Flextool pumps are completely self-priming & extremely robust in their design. The flexible shaft drive facilitates use in many situations where close coupled pumps would not be suitable. The new FP212 series now come with flexshaft support springs which protect the drive shaft when operating over the sharp edge of excavations, pits, dams, etc.

Applications

• Excavations pits
• Construction sites
• Pier holes
• Dams
• Swimming pools
• Trenches

Features

• Heavy-duty and double row oil bath bearings ensure extended service life
• Oil bath lubrication protects against overheating when not submerged in water (runs dry)
• Corrosion resistant stainless-steel spindle for durability
• Seven oil seals provide superior protection to bearings and reduces maintenance intervals
• Hardened steel wear plates protect components from wear and extends service life of pump when used in abrasive pumping applications
• Heavy-duty choke resistant impeller is designed to resist choking and overload when foreign objects enter pump body
• 28 mm solids pumping capacity for rapid pumping of solids in even the toughest of conditions
• Quick-action camlock hose fitting for tool-free and quick connection
• Lifting eyelets for connection of rope or chain when lowering the pump into deep pits to protect flexshaft from scratching
• 3 x 1 metre long flexshaft support springs protect the drive shaft when operating over the sharp edge of excavations, pits, dams, etc.
• Additional 8 metre support rope for use when the pump head is unable to rest on a surface

Specifications

Type	General
Model Number	FP212G-6
Flexshaft Length	6 metres
Operating Weight	26.5kg
Shaft Inner Core Diameter	13mm
Shafting Casing Diameter	32mm
Discharge Diameter	50mm
Max Discharge Head	26m
Max Discharge (l/h)	63,000
Solids Capacity	28mm

• 1 x (FT200032-UNIT) Flextool Lay Flat PVC Hose Assembly 50mm x 20m

Lay Flat Hose is a lightweight, reinforced PVC that can roll flat & save space.

Suitable For

• FT201801-UNIT Flextool Submersible Pump General Purpose 6mt
• FT201802-UNIT Flextool 5.5hp Honda Petrol Powered Drive Unit

Specifications

Length (m)	20 metre
Hose Diameter (mm) (in)	50mm (2")
Fitted With	Coupling & Joiner

Flextool Promise

By registering for the Flextool Promise you’ll have peace of mind that if the unexpected happens and something goes wrong with your Flextool equipment on the job, within the first 12 months of purchase, Flextool will arrange to give you a loan machine for 2 days, free of charge, while they work to repair or replace your Flextool product.
